- Model Number: QDY30A
- Max Measuring Range: 400 Bar & Above
- Brand Name: NoEnName_Null
- Origin: Mainland China
- Certification: CE,FCC,RoHS
- Product name: QDY30A water level sensor
- range: 0-500m H2O customized
- Output signal: 4-20mA,0-10V,0-5V,RS485
- cable lengh: Default 5m,can be customized
- Power supply: DC24V,(dc12-36v)
NOTES!!
This level sensor is DC24V power supply. (DC12-36V can can be used)
Let me know the measuring range, cable length, output signal and power supply if you want to have the customization.TKS
Spcecifications
Tested Medium: Water (liquid that does not corrode stainless steel)
Cable Length: 5m ,10m,15m,20m etc can be customized
Measuring Range: 1m / 2m / 3m / 4m / 5m / 6m/8m/10m/15m (optional)
Measurement Accuracy: 0.2% FS
Output Signal: 4-20mA 0-10v,1-5v RS485 can be customized
Supply Voltage: 12-36VDC
Ambient Temperature: -30-80 ℃
Temperature Compensation: -10-70 ℃
Overload Capacity: <200%
Protection Level: IP68
Long-term Stability: ± 0.2% FS / year
Product Material: 304 stainless steel
Introduction:
<1>. QDY30A submersible Water Level Sensor, its 304 &316 stainless steel and hermetically sealed housing make it suitable for most industrial liquids and oils.
<2>. The welded housing is tested in-house via a helium leak tester to ensure proper protection. Ventilation tube in the cable automatically compensates for changes in atmospheric pressure above the tank. The conductors of the cable are also isolated from the outside environment to keep the level sensor operational for long-term use.
Features:
-
High accuracy
-
High sensitivity
-
Good stability
-
All stainless steel structure probe
-
Anti-corrosion material optional
-
Easy Installation
Technical parameters:
|
Model |
QDY30A liquid water level sensor |
|
Measuring Range |
0~0.5~500m H2O |
|
Power supply |
24VDC |
|
Output Signal |
4-20mA, 0-10V, 0~5V, RS485 |
|
Accuracy |
0.5%FS |
|
Response Time |
≤1ms (up to 90%FS) |
|
Long-term Stability |
±2F.S/Year |
|
Medium Temperature |
-20~85℃ |
|
Working Temperature |
-40~80℃ |
|
Overload Capacity |
200%F.S |
|
Insulation Resistance |
100MΩ/250VDC |
|
Sensitivity Drift |
±2%F.S |
|
Zero Drift |
±2%F.S |
|
Protection |
IP68 |
|
Measuring Medium |
Various medium which is compatible with SS304 |
|
Mechanical Vibration |
20g (20~5000Hz) |
|
Impact |
100g (11MS)100g (11MS) |
|
Material |
Junction box: Low content Cu-Al alloy Probe: Stainless steel Cable: Polyurethane cable |
|
Application |
Static liquid level, Liquid tank, Sewage water, Well, Lake,etc. |
Ordering Guide:
